Check out our range of power conversion series suitable for a vast range of applications.
Minimum order quantities apply on all of our products Please get in touch to see how we can support you on your next Power Supply Application project.
Popular Conversion Series
Popular Conversion Series
Check out our range of power conversion series suitable for a vast range of commercial applications.
Add to shortlist
Compare
Enclosed AC/DC Power Supply10PLS-600-48
The 10PLS-600-XX is a Single output 48V DC 12.5A 600WW model and offers consistent output for embedded systems. The 10PLS-600-XX Series is a consistent and reliable Internal Power Supply (PSU). Designed for use in applications such as commercial AV, broadcasting and control panels. This series is supplied with a Terminal Block input connection. Certified to CE, CQC, RoHS, REACH and compliant with EN IEC 62368-1/GB 4943.1. Suitable for integration in diverse AV, ITE, and embedded electronic systems — view the full range. If you can’t find what you need, contact us for alternative or customised options.
Features
- Approved to CE, CQC, RoHS, REACH
- Compact
- High-efficiency <88%
- Low leakage current: <2mA @ 240V AC
- Operating altitude: up to 5,000m
- Operating temp: -30°C to +70°C
- Universal Input: 90~132V AC / 180~264V AC (switch selectable)
Basic Specification
| Product Type | Internal Power Supply (PSU) Enclosed Power Supplies |
|---|---|
| Input Voltage | 90~132V AC |
| Output | 48V DC 12.5A |
| Output Power | 600W |
| Number of Outputs | Single |
| Efficiency | 88 |
| Output Connector | Terminal Block |
| Dimensions | 225 x 124 x 35mm |
| Industry | ITE, Audio & Video |
| Standards | EN IEC 62368-1, GB 4943.1 |
Other Models in this series
| Compare | Model | Image | Output Voltage | Current | Power | Additional Info |
|---|---|---|---|---|---|---|
Compare |
10PLS-600-42 | |
42V DC | 14.2A | 596.5W | Download Pdf |
Compare |
10PLS-600-36 | |
36V DC | 16.6A | 597.5W | Download Pdf |
Compare |
10PLS-600-12 | |
12V DC | 50A | 600W | Download Pdf |
Compare |
10PLS-600-15 | |
15V DC | 40A | 600W | Download Pdf |
Compare |
10PLS-600-24 | |
24V DC | 25A | 600W | Download Pdf |
Related Series
10PLS-50-XX Series
- Approved to CE, cULus, CCC, EAC, CB, RoHS, REACH
- Compact
- High-efficiency <90%
- Input Voltage 90~264V AC (120~430V DC)
- Low leakage current: <0.5mA @ 240V AC
- Operating altitude: up to 5,000m
- Operating temp: -30°C to +70°C
Compare
10PLS-75-XX Series
- Approved to UKCA, CE, cULus, FCC, CCC, EAC, CB, RoHS, REACH
- Compact
- High-efficiency <89%
- Input Voltage 90~264V AC (120~430V DC)
- Low leakage current: <0.5mA @ 240V AC
- Operating altitude: up to 5,000m
- Operating temp: -30°C to +70°C
Compare
10PLS-100-XX Series
- Approved to UKCA, CE, cULus, FCC, CCC, EAC, CB, RoHS, REACH
- Compact
- High-efficiency <91%
- Input Voltage 90~264V AC (120~430V DC)
- Low leakage current: <0.5mA @ 240V AC
- Operating altitude: up to 5,000m
- Operating temp: -30°C to +70°C
Compare
10PLS-150-XX Series
- Approved to UKCA, CE, cULus, FCC, CCC, EAC, CB, RoHS, REACH
- Compact
- High-efficiency <89%
- Input Voltage 90~264V AC (120~430V DC)
- Low leakage current: <03.5mA @ 240V AC, grounded / <0.25 mA @ 240 V AC, ungrounded
- Operating altitude: up to 5,000m
- Operating temp: -30°C to +70°C
Compare
10PLS-200-XX Series
- Approved to UKCA, CE, cULus, FCC, CQC, EAC, CB, RoHS, REACH
- Compact
- High-efficiency <89%
- Low leakage current: <0.5mA @ 240V AC
- Operating altitude: up to 5,000m
- Operating temp: -30°C to +70°C
- Universal Input: 90~132V AC (180~264V DC) 240~730V DC
Compare
10PLS-350-XX Series
- Approved to UKCA, CE, cULus, FCC, CQC, EAC, CB, RoHS, REACH
- Compact
- High-efficiency <88%
- Input Voltage 90~132 V AC, 180~264 V AC (switchable)
- Low leakage current: <0.5mA @ 240V AC
- Operating altitude: up to 5,000m
- Operating temp: -30°C to +70°C
Compare
