200W Enclosed AC/DC Power Supply10PLS-200-XX Series

The 10PLS-200-XX Series is a consistent and high-performing Internal Power Supply (PSU). Designed for use in applications such as embedded electronics and control equipment. This series is supplied with a Terminal Block input connection. Certified to UKCA, CE, cULus, FCC, CQC, EAC, CB, RoHS, REACH and compliant with EN IEC 62368-1/EN IEC 62368-1/IEC 62368-1. This product range is engineered to streamline hardware development in IT, audio, and video applications — contact us for expert guidance. If you can’t find what you need, contact us for alternative or customised options.

Features

Approved to UKCA, CE, cULus, FCC, CQC, EAC, CB, RoHS, REACH
Compact
High-efficiency <89%
Low leakage current: <0.5mA @ 240V AC
Operating altitude: up to 5,000m
Operating temp: -30°C to +70°C
Universal Input: 90~132V AC (180~264V DC) 240~730V DC

Basic Specification

Product Type	Internal Power Supply (PSU) Enclosed Power Supplies
Input Voltage	90~132V AC
Output Power	200W
Input Connection	Terminal Block
Isolation	Input~Output: 3750V AC, Input~Ground: 2000V AC, Output~Ground: 500V AC
Dimensions	215 x 115 x 30mm
Industry	ITE, Audio & Video
Standards	EN IEC 62368-1, EN IEC 62368-1, IEC 62368-1
