Enclosed AC/DC Power Supply10PLS-600-36
The 10PLS-600-XX is a Single output 36V DC 16.6A 597.5WW model and delivers clean power for small-scale electronic designs. The 10PLS-600-XX Series is a consistent and reliable Internal Power Supply (PSU). Designed for use in applications such as commercial AV, broadcasting and control panels. This series is supplied with a Terminal Block input connection. Certified to CE, CQC, RoHS, REACH and compliant with EN IEC 62368-1/GB 4943.1. Suitable for integration in diverse AV, ITE, and embedded electronic systems — view the full range. If you can’t find what you need, contact us for alternative or customised options.
Features
- Approved to CE, CQC, RoHS, REACH
- Compact
- High-efficiency <88%
- Low leakage current: <2mA @ 240V AC
- Operating altitude: up to 5,000m
- Operating temp: -30°C to +70°C
- Universal Input: 90~132V AC / 180~264V AC (switch selectable)
Basic Specification
| Product Type | Internal Power Supply (PSU) Enclosed Power Supplies |
|---|---|
| Input Voltage | 90~132V AC |
| Output | 36V DC 16.6A |
| Output Power | 597.5W |
| Number of Outputs | Single |
| Efficiency | 88 |
| Output Connector | Terminal Block |
| Dimensions | 225 x 124 x 35mm |
| Industry | ITE, Audio & Video |
| Standards | EN IEC 62368-1, GB 4943.1 |
Other Models in this series
| Compare | Model | Image | Output Voltage | Current | Power | Additional Info |
|---|---|---|---|---|---|---|
Compare |
10PLS-600-42 | |
42V DC | 14.2A | 596.5W | Download Pdf |
Compare |
10PLS-600-48 | |
48V DC | 12.5A | 600W | Download Pdf |
Compare |
10PLS-600-12 | |
12V DC | 50A | 600W | Download Pdf |
Compare |
10PLS-600-15 | |
15V DC | 40A | 600W | Download Pdf |
Compare |
10PLS-600-24 | |
24V DC | 25A | 600W | Download Pdf |
Related Series
10PLS-50-XX Series
- Approved to CE, cULus, CCC, EAC, CB, RoHS, REACH
- Compact
- High-efficiency <90%
- Input Voltage 90~264V AC (120~430V DC)
- Low leakage current: <0.5mA @ 240V AC
- Operating altitude: up to 5,000m
- Operating temp: -30°C to +70°C
Compare
10PLS-75-XX Series
- Approved to UKCA, CE, cULus, FCC, CCC, EAC, CB, RoHS, REACH
- Compact
- High-efficiency <89%
- Input Voltage 90~264V AC (120~430V DC)
- Low leakage current: <0.5mA @ 240V AC
- Operating altitude: up to 5,000m
- Operating temp: -30°C to +70°C
Compare
10PLS-100-XX Series
- Approved to UKCA, CE, cULus, FCC, CCC, EAC, CB, RoHS, REACH
- Compact
- High-efficiency <91%
- Input Voltage 90~264V AC (120~430V DC)
- Low leakage current: <0.5mA @ 240V AC
- Operating altitude: up to 5,000m
- Operating temp: -30°C to +70°C
Compare
10PLS-150-XX Series
- Approved to UKCA, CE, cULus, FCC, CCC, EAC, CB, RoHS, REACH
- Compact
- High-efficiency <89%
- Input Voltage 90~264V AC (120~430V DC)
- Low leakage current: <03.5mA @ 240V AC, grounded / <0.25 mA @ 240 V AC, ungrounded
- Operating altitude: up to 5,000m
- Operating temp: -30°C to +70°C
Compare
10PLS-200-XX Series
- Approved to UKCA, CE, cULus, FCC, CQC, EAC, CB, RoHS, REACH
- Compact
- High-efficiency <89%
- Low leakage current: <0.5mA @ 240V AC
- Operating altitude: up to 5,000m
- Operating temp: -30°C to +70°C
- Universal Input: 90~132V AC (180~264V DC) 240~730V DC
Compare
10PLS-350-XX Series
- Approved to UKCA, CE, cULus, FCC, CQC, EAC, CB, RoHS, REACH
- Compact
- High-efficiency <88%
- Input Voltage 90~132 V AC, 180~264 V AC (switchable)
- Low leakage current: <0.5mA @ 240V AC
- Operating altitude: up to 5,000m
- Operating temp: -30°C to +70°C
