Home / Internal Power Supply (PSU) / Enclosed Power Supplies / 10PLS-600-XX

Compare

600W Enclosed AC/DC Power Supply10PLS-600-XX Series

The 10PLS-600-XX Series is a consistent and reliable Internal Power Supply (PSU). Designed for use in applications such as commercial AV, broadcasting and control panels. This series is supplied with a Terminal Block input connection. Certified to CE, CQC, RoHS, REACH and compliant with EN IEC 62368-1/GB 4943.1. Suitable for integration in diverse AV, ITE, and embedded electronic systems — view the full range. If you can’t find what you need, contact us for alternative or customised options.

Features

Approved to CE, CQC, RoHS, REACH
Compact
High-efficiency <88%
Low leakage current: <2mA @ 240V AC
Operating altitude: up to 5,000m
Operating temp: -30°C to +70°C
Universal Input: 90~132V AC / 180~264V AC (switch selectable)

Basic Specification

Product Type	Internal Power Supply (PSU) Enclosed Power Supplies
Input Voltage	90~132V AC
Output Power	600W
Input Connection	Terminal Block
Isolation	Input~Output: 3750V AC, Input~Ground: 2000V AC, Output~Ground: 500V AC
Dimensions	225 x 124 x 35mm
Industry	ITE, Audio & Video
Standards	EN IEC 62368-1, GB 4943.1

Pdf Spec Sheet

Models in this series

Compare Products 0/4

Compare	Model	Output Voltage	Current	Power	Additional Info
Compare	10PLS-600-42	42V DC	14.2A	596.5W	Download Pdf
Compare	10PLS-600-36	36V DC	16.6A	597.5W	Download Pdf
Compare	10PLS-600-48	48V DC	12.5A	600W	Download Pdf
Compare	10PLS-600-12	12V DC	50A	600W	Download Pdf
Compare	10PLS-600-15	15V DC	40A	600W	Download Pdf
Compare	10PLS-600-24	24V DC	25A	600W	Download Pdf
