Enclosed AC/DC Power Supply10PLS-450-42

10PLS-450-42

The 10PLS-450-XX is a Single output 42V DC 10.7A 449.5WW model and delivers dependable performance where it matters most. The 10PLS-450-XX Series is a high-efficiency and standards-compliant Internal Power Supply (PSU). Designed for use in applications such as industrial control and automation systems. This series is supplied with a Terminal Block input connection. Certified to CE, CQC, RoHS, REACH and compliant with EN IEC 62368-1 + A11/GB 4943.1. Ideal for AV and ITE manufacturers, this product range offers efficient, adaptable power units for demanding environments. If you can’t find what you need, contact us for alternative or customised options.

Features

  • Approved to CE, CQC, RoHS, REACH
  • Compact
  • High-efficiency ≤92%
  • Low leakage current: <2mA @ 240V AC
  • Operating altitude: up to 5,000m
  • Operating temp: -30°C to +70°C
  • Universal Input: 90~132V AC / 180~264V AC (switch selectable)

Basic Specification

Product Type Internal Power Supply (PSU) Enclosed Power Supplies
Input Voltage 90~132V AC
Output 42V DC 10.7A
Output Power 449.5W
Number of Outputs Single
Efficiency 92%
Output Connector Terminal Block
Dimensions 225 x 124 x 35mm
Industry ITE, Audio & Video
Standards EN IEC 62368-1, GB 4943.1

Speak To The Power Supply & Conversion Experts

Get In Touch

Other Models in this series

Compare Model Image Output Voltage Current Power Additional Info
Compare
10PLS-450-15
10PLS-450-15
15V DC 30A 450W Download Pdf
Compare
10PLS-450-36
10PLS-450-36
36V DC 12.5A 450W Download Pdf
Compare
10PLS-450-48
10PLS-450-48
48V DC 9.4A 451W Download Pdf
Compare
10PLS-450-24
10PLS-450-24
24V DC 18.8A 451W Download Pdf
Compare
10PLS-450-12
10PLS-450-12
12V DC 47.5A 570W Download Pdf
