450W Enclosed AC/DC Power Supply10PLS-450-XX Series

The 10PLS-450-XX Series is a high-efficiency and standards-compliant Internal Power Supply (PSU). Designed for use in applications such as industrial control and automation systems. This series is supplied with a Terminal Block input connection. Certified to CE, CQC, RoHS, REACH and compliant with EN IEC 62368-1 + A11/GB 4943.1. Ideal for AV and ITE manufacturers, this product range offers efficient, adaptable power units for demanding environments. If you can’t find what you need, contact us for alternative or customised options.

Features

Approved to CE, CQC, RoHS, REACH
Compact
High-efficiency ≤92%
Low leakage current: <2mA @ 240V AC
Operating altitude: up to 5,000m
Operating temp: -30°C to +70°C
Universal Input: 90~132V AC / 180~264V AC (switch selectable)

Basic Specification

Product Type	Internal Power Supply (PSU) Enclosed Power Supplies
Input Voltage	90~132V AC 47~63Hz
Output Power	450W
Input Connection	Terminal Block
Isolation	Input~Output: 3750V AC, Input~Ground: 2000V AC, Output~Ground: 500V AC
Dimensions	225 x 124 x 35mm
Industry	ITE, Audio & Video
Standards	EN IEC 62368-1, GB 4943.1

Pdf Spec Sheet

Models in this series

Compare Products 0/4

Compare	Model	Output Voltage	Current	Power	Additional Info
Compare	10PLS-450-42	42V DC	10.7A	449.5W	Download Pdf
Compare	10PLS-450-15	15V DC	30A	450W	Download Pdf
Compare	10PLS-450-36	36V DC	12.5A	450W	Download Pdf
Compare	10PLS-450-24	24V DC	18.8A	451W	Download Pdf
Compare	10PLS-450-48	48V DC	9.4A	451W	Download Pdf
Compare	10PLS-450-12	12V DC	47.5A	570W	Download Pdf
