Enclosed AC/DC Power Supply10PLS-350-15

The 10PLS-350-XX is a Single output 15V DC 23.2A 348WW model and offers consistent output for embedded systems. The 10PLS-350-XX Series is a performance-focused Internal Power Supply (PSU). Designed for use in applications such as network equipment and signal distribution hardware. This series is supplied with a Terminal Block input connection. Certified to UKCA, CE, cULus, FCC, CQC, EAC, CB, RoHS, REACH and compliant with EN IEC 62368-1/EN IEC 62368-1/IEC 62368-1. This product range is ideal for embedded use across ITE, audio, and visual system designs — view related products. If you can’t find what you need, contact us for alternative or customised options.

Features

Approved to UKCA, CE, cULus, FCC, CQC, EAC, CB, RoHS, REACH
Compact
High-efficiency <88%
Input Voltage 90~132 V AC, 180~264 V AC (switchable)
Low leakage current: <0.5mA @ 240V AC
Operating altitude: up to 5,000m
Operating temp: -30°C to +70°C

Basic Specification

Product Type	Internal Power Supply (PSU) Enclosed Power Supplies
Input Voltage	90~132V AC
Output	15V DC 23.2A
Output Power	348W
Number of Outputs	Single
Efficiency	86
Output Connector	Terminal Block
Dimensions	215 x 115 x 30mm
Industry	ITE, Audio & Video
Standards	EN IEC 62368-1, EN IEC 62368-1, IEC 62368-1

Pdf Spec Sheet

Other Models in this series

Compare Products 0/4

Compare	Model	Output Voltage	Current	Power	Additional Info
Compare	10PLS-350-12	12V DC	29A	348W	Download Pdf
Compare	10PLS-350-36	36V DC	9.7A	349W	Download Pdf
Compare	10PLS-350-48	48V DC	7.3A	350.5W	Download Pdf
Compare	10PLS-350-24	24V DC	14.6A	350.5W	Download Pdf
Compare	10PLS-350-54	54V DC	6.5A	351W	Download Pdf
