Enclosed AC/DC Power Supply10PLS-150-15
The 10PLS-150-XX is a Single output 15V DC 10A 150WW model and is a dependable choice for integrators and developers. The 10PLS-150-XX Series is a high-performance Internal Power Supply (PSU). Designed for use in applications such as digital signage, displays and user interfaces. This series is supplied with a Terminal Block input connection. Certified to UKCA, CE, cULus, FCC, CCC, EAC, CB, RoHS, REACH and compliant with EN IEC 62368-1/IEC 62368-1/BS EN IEC 62368-1/EN IEC 62368-1/GB 4943.1/UL 62368-1. This product range supports reliable performance in multimedia, ITE, and AV hardware — see the full range. If you can’t find what you need, contact us for alternative or customised options.
Features
- Approved to UKCA, CE, cULus, FCC, CCC, EAC, CB, RoHS, REACH
- Compact
- High-efficiency <89%
- Input Voltage 90~264V AC (120~430V DC)
- Low leakage current: <03.5mA @ 240V AC, grounded / <0.25 mA @ 240 V AC, ungrounded
- Operating altitude: up to 5,000m
- Operating temp: -30°C to +70°C
Basic Specification
| Product Type | Internal Power Supply (PSU) Enclosed Power Supplies |
|---|---|
| Input Voltage | 90~264V AC |
| Output | 15V DC 10A |
| Output Power | 150W |
| Number of Outputs | Single |
| Efficiency | 86 |
| Output Connector | Terminal Block |
| Dimensions | 159 x 97 x 30mm |
| Industry | ITE, Audio & Video |
| Standards | EN IEC 62368-1, IEC 62368-1, BS EN IEC 62368-1, EN IEC 62368-1, GB 4943.1, UL 62368-1 |
Other Models in this series
| Compare | Model | Image | Output Voltage | Current | Power | Additional Info |
|---|---|---|---|---|---|---|
Compare |
10PLS-150-12 | |
12V DC | 12.5A | 150W | Download Pdf |
Compare |
10PLS-150-24 | |
24V DC | 6.3A | 151W | Download Pdf |
Compare |
10PLS-150-36 | |
36V DC | 4.2A | 151W | Download Pdf |
Compare |
10PLS-150-54 | |
54V DC | 2.8A | 151W | Download Pdf |
Compare |
10PLS-150-48 | |
48V DC | 3.2A | 153.5W | Download Pdf |
Related Series
10PLS-50-XX Series
- Approved to CE, cULus, CCC, EAC, CB, RoHS, REACH
- Compact
- High-efficiency <90%
- Input Voltage 90~264V AC (120~430V DC)
- Low leakage current: <0.5mA @ 240V AC
- Operating altitude: up to 5,000m
- Operating temp: -30°C to +70°C
Compare
10PLS-75-XX Series
- Approved to UKCA, CE, cULus, FCC, CCC, EAC, CB, RoHS, REACH
- Compact
- High-efficiency <89%
- Input Voltage 90~264V AC (120~430V DC)
- Low leakage current: <0.5mA @ 240V AC
- Operating altitude: up to 5,000m
- Operating temp: -30°C to +70°C
Compare
10PLS-100-XX Series
- Approved to UKCA, CE, cULus, FCC, CCC, EAC, CB, RoHS, REACH
- Compact
- High-efficiency <91%
- Input Voltage 90~264V AC (120~430V DC)
- Low leakage current: <0.5mA @ 240V AC
- Operating altitude: up to 5,000m
- Operating temp: -30°C to +70°C
Compare
10PLS-200-XX Series
- Approved to UKCA, CE, cULus, FCC, CQC, EAC, CB, RoHS, REACH
- Compact
- High-efficiency <89%
- Low leakage current: <0.5mA @ 240V AC
- Operating altitude: up to 5,000m
- Operating temp: -30°C to +70°C
- Universal Input: 90~132V AC (180~264V DC) 240~730V DC
Compare
10PLS-350-XX Series
- Approved to UKCA, CE, cULus, FCC, CQC, EAC, CB, RoHS, REACH
- Compact
- High-efficiency <88%
- Input Voltage 90~132 V AC, 180~264 V AC (switchable)
- Low leakage current: <0.5mA @ 240V AC
- Operating altitude: up to 5,000m
- Operating temp: -30°C to +70°C
Compare
10PLS-600-XX Series
- Approved to CE, CQC, RoHS, REACH
- Compact
- High-efficiency <88%
- Low leakage current: <2mA @ 240V AC
- Operating altitude: up to 5,000m
- Operating temp: -30°C to +70°C
- Universal Input: 90~132V AC / 180~264V AC (switch selectable)
Compare
