Open Frame Chassis Power Supplies

Open frame chassis power supplies are internal AC-DC conversion units designed for direct integration into electronic equipment where space efficiency, airflow and system flexibility are key considerations. Without a fully enclosed casing, these power supplies are intended to be installed within protected equipment housings, allowing designers to optimise layout and thermal performance.

At Ideal Power, our range of open frame power supplies supports a wide selection of output voltages and power ratings suitable for industrial control systems, ITE equipment, instrumentation and embedded applications. Each model includes clear electrical specifications and compliance information to support accurate and confident product selection.

Efficient Power for Integrated System Designs

Open frame power supplies are engineered to deliver regulated DC output while maintaining high operating efficiency. Their exposed chassis design supports improved airflow within equipment enclosures, helping manage heat dissipation in compact or densely populated systems.

These units are commonly selected where internal installation is required and where mechanical flexibility is important during system design and assembly.

Common Applications for Open Frame Power Supplies

Open frame PSUs are widely used in:

• Industrial automation and control systems
• Information technology equipment (ITE)
• Measurement and instrumentation devices
• Embedded electronic systems
• OEM equipment manufacturing

Their adaptable mounting options and efficient operation make them suitable for a broad range of commercial and industrial applications.

How to Choose the Right Open Frame Power Supply

When selecting an open frame chassis PSU, consider the following:

• Output Voltage and Current – Ensure the power supply matches total load requirements.
• Mechanical Dimensions – Confirm compatibility with available enclosure space.
• Cooling and Airflow – Assess ventilation within the final equipment housing.
• Compliance and Safety Standards – Verify that the unit meets relevant regulatory requirements.

Selecting the correct open frame power supply ensures stable operation, efficient performance and reliable long-term integration within your equipment design.

Frequently Asked Questions

What types of products are included in the Open frame and chassis power supplies range?

Our open frame and chassis power supply range includes open frame AC/DC power supplies and chassis-mounted units designed for internal integration into electronic equipment. These products cover a wide range of output voltages and power ratings to suit applications from compact embedded systems to higher-power industrial and ITE equipment. Each product page provides clear electrical and mechanical specifications to support accurate comparison and selection.

How do I choose the right Open frame and chassis power supplies for my application?

Start by confirming the required input voltage, output voltage, and output current, along with any safety or regulatory approvals required for your end product. You should also consider form factor, mounting method, thermal management, airflow requirements, and available space within the enclosure. If you need guidance, share your electrical requirements and operating conditions with our team and we will help identify suitable open frame or chassis power supply options.

Are the open frame and chassis power supplies certified and compliant with relevant safety standards?

Yes. Our open frame and chassis power supplies are sourced from approved manufacturers and are produced to meet relevant international safety and EMC standards for their intended markets. Individual datasheets list applicable approvals such as IEC, EN, UL, UKCA, and CE, along with efficiency and compliance information where relevant. If you require confirmation for a specific standard or application, please contact our technical team with the part number.

What are the typical lead times and is technical support available for open frame and chassis power supplies?

Open frame and chassis power supplies are supplied to order on standard manufacturer lead times. To confirm current lead times, please contact our sales team, who can advise based on your requirements. Our engineers are available to provide technical support, assist with cross-referencing, and advise on the most suitable power supply for your application.
