Encapsulated AC/DC Power Supply56YSM20-2400630

The YSM20-2400630 is a Single output 24V DC 0.63A 15.12W model and provides the performance expected in trusted applications. The 56YSM20-xy Series is a regulated and reliable 20W Enclosed AC/DC Power Supply. Designed for use in applications such as system-critical media and control infrastructure. This series is supplied with a Pin Connection input connection and supports input voltages of 90~264V AC 50~60Hz. Certified to CE, CB, cULus, RoHS, REACH and compliant with BS EN 62368-1/UL 62368-1. Perfect for system builders and AV/IT engineers, this product range delivers flexible integration — get in touch for technical support. If you can’t find what you need, contact us for alternative or tailored options.

Features

• Input Voltage Range 90-264V AC
• No-load power consumption < 0.1 W
• Operating Temperature Range: -30°C~+70°C
• Efficiency up to 82%
• Safety Standards to IEC/UL 62368-1
• Output SCP, OLP, OVP
• Three Years Warranty

Basic Specification

Product Type	Internal Power Supply (PSU) PCB Mount Power Supplies
Input Voltage	90~264V AC
Output	24V DC 0.63A
Output Power	15.1W
Number of Outputs	Single
Efficiency	83.0%
Output Connector	Pin Connection
Dimensions	52.4x27.2x24mm
Industry	ITE, Audio & Video
Standards	EN 62368-1, IEC 62368-1, UL 62368-1

Also Available From

CPC

Product Code: PW06373

Direct Replacement For

This product is a direct replacement for the part numbers listed below. If your project currently uses one of these products, you can replace it with this model without any compatibility issues.

• Meanwell: IRM-15-24
