PCB Mount Medical AC DC Power Supply41GA10M-S24-B

The GA10M-S24-B is a Single output 24V DC 0.46A 11W model and suits medical examination instruments that need 4KV AC isolation, with 80-264V AC input and 2 x MOPP medical safety design. The 41GA10M-B Series is a 10W PCB mount medical AC/DC power supply module with single 5V, 12V, 15V and 24V DC outputs. Designed to 2 x MOPP, with no-load power consumption below 0.1W and no minimum load, it suits portable medical devices, mobile clinical workstations, medical computer monitors and examination instruments. This series is supplied with a Pin Connection input connection and supports input voltages of 80-264V AC 47-63Hz. Certified to CE, cURus, CB, RoHS and REACH, and compliant with IEC 62368-1/EN 62368-1/IEC 60601-1/EN 60601-1/UL/CSA 62368-1 Standards. These are primarily used in ITE, Audio & Video and Medical Industries, and customised solutions are available upon request.
