56YMC15D-xy SERIES

15W DIN Rail Mount AC/DC Power upply Converter

Certified to UKCA, CE, TUV-GS, RoHS, REACH & EN 62368-1/IEC 62368-1 Standards and complies with Efficiency Regulations. These are primarily used in ITE, Audio & Video Industries and customised solutions are available upon request.

Features

Certified to: UKCA, CE, TUV-GS, RoHS & REACH - UL Pending
Operating Temperature: 40°C~+85°C
Protection: SCP, OCP, OVP
Safety Standards to IEC/EN 62368-1
Super Small Design
Three Years Warranty
Ultra-wide Voltage Input Range 85~305V AC or 100~430V DC

Basic Specification

Product Type	Internal Power Supply (PSU) DIN Rail Power Supplies
Input Voltage	85~305V AC 47~63Hz
Output Power	15W
Number of Outputs	Single
Input Connection	DIN Rail
Isolation	500V DC
Dimensions	76x31.5x36.9mm
Industry	ITE, Audio & Video
Standards	EN 62368-1, IEC 62368-1

Pdf Spec Sheet

Models in this series

Compare Products 0/4

Compare	Model	Output Voltage	Current	Power	Additional Info
Compare	56YMC15D-3.3	3.3V DC	4A	13.2W	Download Pdf
Compare	56YMC15D-5	5V DC	3A	15W	Download Pdf
Compare	56YMC15D-9	9V DC	1.67A	15W	Download Pdf
Compare	56YMC15D-12	12V DC	1.25A	15W	Download Pdf
Compare	56YMC15D-15	15V DC	1A	15W	Download Pdf
Compare	56YMC15D-24	24V DC	0.625A	15W	Download Pdf
