44ATM090T-P190

AC/DC External Desktop Medical Power Supply (PSU)

Ideal Power's 44ATM090T-Pxyz 90W AC/DC External Desktop Medical Power Supply (PSU) Series is certified to cULus, UKCA, CB, PSE, FCC, CE, TUV, RoHS, REACH & EN 60601-1/IEC 60601-1/ES 60601-1 Standards and complies with (EU) 2019/1782, Level VI Efficiency Regulations. These are primarily used in Medical, ITE, Audio & Video Industries and customised solutions are available upon request.

Pdf Spec Sheet

Add compare

Features

Approved to cULus, UKCA, CB, PSE, FCC, CE, RoHS & REACH
Earthed/Ground connected to 0V
IEC 60601-1-2:2014(ED 4.0) Safety Approved
Means of Protection: 2 X MOPP
Meets Efficiency Level VI
Single Output 12~24V DC
Universal Input 100~240V AC

Basic Specification

Product Type	External Power Supply (PSU) Desktop Power Supply
Input Voltage	90~264V AC
Output	19V DC 4.74A
Output Power	90.1W
Number of Outputs	Single
Efficiency
Output Connector	2.1 x 5.5 x 11 mm
Dimensions	160x64x35mm
Industry	Medical, ITE, Audio & Video
Standards	EN 60601-1, IEC 60601-1, ES 60601-1

Also Available From

Digikey

Product Code: 2882-44ATM090T-P190-ND

Farnell

Product Code: 3798176

CPC

Product Code: PW05004

Contact us

Reach out to discuss your power conversion requirements today.

Declaration

Click below to request the Series Declaration (PDF Download).

Request Declaration

Other Models in this series

Compare Products 0/4

Compare	Model		Output Voltage	Current	Power	Additional Info
Compare	44ATM090T-P120	44ATM090T-P120	12V DC	7A	84W	Download Pdf
Compare	44ATM090T-P150	44ATM090T-P150	15V DC	6A	90W	Download Pdf
Compare	44ATM090T-P180	44ATM090T-P180	18V DC	5A	90W	Download Pdf
Compare	44ATM090T-P240	44ATM090T-P240	24V DC	3.75A	90W	Download Pdf
