15DYS824-075280W-K

AC/DC External Adapter Interchangeable Power Supply

Ideal Power's 15DYS824-xyW-K 24W AC/DC External Adapter Interchangeable Power Supply (PSU) Series is certified to UKCA, CE, cULus, TUV, RCM (C-Tick), FCC, RoHS, REACH & EN 62368-1/IEC 62368-1 Standards and complies with (EU) 2019/1782, Level VI Efficiency Regulations. These are primarily used in ITE, Audio & Video Industries and customised solutions are available upon request.

Pdf Spec Sheet

Add compare

Features

Approved to CE, TUV, cULus, RCM (C-Tick), RoHS & REACH
EMC Class B Certified
Interchangeable Power Supply
Meets Efficiency Level VI
OVP, OCP, OTP, SCP
Single Output 5~30V DC
UL/IEC/EN 62368-1 Safety Approved
Universal Input 100~240V AC

Basic Specification

Product Type	External Power Supply (PSU) Adapter Interchangeable Power Supply
Input Voltage	90~264V AC
Output	7.5V DC 2.8A
Output Power	21W
Number of Outputs	Single
Efficiency
Output Connector	2.1 x 5.5 x 12 mm
Dimensions	76.8x47.5x35mm
Industry	ITE, Audio & Video
Standards	EN 62368-1, IEC 62368-1

Also Available From

Digikey

Product Code: 2882-15DYS824-075280W-K-ND

Farnell

Product Code: 3370078

CPC

Product Code: PW04153

Contact us

Reach out to discuss your power conversion requirements today.

Declaration

Click below to request the Series Declaration (PDF Download).

Request Declaration

Other Models in this series

Compare Products 0/4

Compare	Model		Output Voltage	Current	Power	Additional Info
Compare	15DYS824-050400W-K	15DYS824-050400W-K	5V DC	4A	20W	Download Pdf
Compare	15DYS824-090250W-K	15DYS824-090250W-K	9V DC	2.5A	22.5W	Download Pdf
Compare	15DYS824-180133W-K	15DYS824-180133W-K	18V DC	1.33A	23.9W	Download Pdf
Compare	15DYS824-240100W-K	15DYS824-240100W-K	24V DC	1A	24W	Download Pdf
Compare	15DYS824-300080W-K	15DYS824-300080W-K	30V DC	0.8A	24W	Download Pdf
Compare	15DYS824-120200W-K	15DYS824-120200W-K	12V DC	2A	24W	Download Pdf
Compare	15DYS824-150160W-K	15DYS824-150160W-K	15V DC	1.6A	24W	Download Pdf
