Encapsulated AC DC Power Supply41GA10M-S24B

Name: 41GA10M-S24B Encapsulated AC DC Power Supply
Brand: Ideal Power
SKU: 41GA10M-S24B
Availability: InStock

The 41GA10M-SXB is a Single output 24V 0.46A 11.04WW model and delivers dependable performance where it matters most. The 41GA10M-SXB Series is a medically approved and reliable Internal Power Supply (PSU)>PCB Mount Power Supplies. Designed for use in applications such as clinical, imaging and diagnostic systems. This series is supplied with a Pin Connection input connection. Certified to UL, CB, CE, RoHS & REACH and compliant with IEC EN62368-1/EN 62368-1/IEC 60601-1/EN 60601-1. This product range supports demanding medical, ITE, and AV applications where healthcare compliance and reliability are non-negotiable. If you can’t find what you need, contact us for alternative or customised options.

Features

83% Efficiency
Approved to UL, CB, CE, RoHS & REACH
EMI class B for class ? configuration
Extremely low leakage current
IEC/EN62368-1,IEC/EN60601-1Safety Approved
Single Output 5-24V DC
Universal Input Voltage Range 80~264V AC

Basic Specification

Product Type	Internal Power Supply (PSU) PCB Mount Power Supplies
Input Voltage	80~264V AC
Output	24V DC 0.46A
Number of Outputs	Single
Efficiency	83%
Output Connector	Pin Connection
Dimensions	52.70x27.30x20mm
Industry	ITE, Audio & Video, Medical
Standards	IEC EN62368-1, EN 62368-1, IEC 60601-1, EN 60601-1
