Encapsulated AC/DC PCB Mount Power Supply56YMC20-12
The YMC20-12 is a Single output 12V DC 1.8A 21.6W model and is a dependable choice for integrators and developers. The 56YMC20-xx Series is a high-efficiency and standards-compliant 20W Encapsulated AC/DC PCB Mount Power Supply. Designed for use in applications such as industrial control and automation systems. This series is supplied with a Pin Connection input connection and supports input voltages of 85~305V AC 47~63Hz. Certified to UKCA, CE, TUV-GS, RoHS, REACH and compliant with EN 62368-1/IEC 62368-1. Ideal for AV and ITE manufacturers, this product range offers efficient, adaptable power units for demanding environments. If you can’t find what you need, contact us for alternative or tailored options.
Features
- Wide Input Voltage Range 85-305V AC
- Super Small Design
- Operating Temperature: 40°C~+85°C
- Safety Standards to IEC/EN 62368-1
- Certified to: UKCA, CE, TUV-GS, RoHS & REACH - UL Pending
- Protection: SCP, OCP, OVP
- Three Years Warranty
Basic Specification
| Product Type | Internal Power Supply (PSU) PCB Mount Power Supplies |
|---|---|
| Input Voltage | 85~305V AC |
| Output | 12V DC 1.8A |
| Output Power | 21.6W |
| Number of Outputs | Single |
| Efficiency | 86.00% |
| Output Connector | Pin Connection |
| Dimensions | 52.4x27.2x24mm |
| Industry | ITE, Audio & Video |
| Standards | EN 62368-1, IEC 62368-1 |
Direct Replacement For
This product is a direct replacement for the part numbers listed below. If your project currently uses one of these products, you can replace it with this model without any compatibility issues.
- Meanwell: IRM-20-12
- Mornsun: LD20-23B12R2
Other Models in this series
| Compare | Model | Image | Output Voltage | Current | Power | Additional Info |
|---|---|---|---|---|---|---|
Compare |
56YMC20-3.3 | |
3.3V DC | 4.5A | 14.9W | Download Pdf |
Compare |
56YMC20-9 | |
9V DC | 2.2A | 19.8W | Download Pdf |
Compare |
56YMC20-5 | |
5V DC | 4A | 20W | Download Pdf |
Compare |
56YMC20-15 | |
15V DC | 1.4A | 21W | Download Pdf |
Compare |
56YMC20-24 | |
24V DC | 0.9A | 21.6W | Download Pdf |
Related Series
56YMC20-xxD Series
- Certified to: UKCA, CE, TUV-GS, RoHS & REACH - UL Pending
- Operating Temperature: 40°C~+85°C
- Protection: SCP, OCP, OVP
- Safety Standards to IEC/EN 62368-1
- Super Small Design
- Three Years Warranty
- Wide Input Voltage Range 85-305V AC
Compare
56YMC20-xxT Series
- Certified to: UKCA, CE, TUV-GS, RoHS & REACH - UL Pending
- Operating Temperature: 40°C~+85°C
- Protection: SCP, OCP, OVP
- Safety Standards to IEC/EN 62368-1
- Super Small Design
- Three Years Warranty
- Wide Input Voltage Range 85-305V AC
Compare
