20W Interchangeable PD Charger02PD-xy-C Series

The 02PD-xy-C Series is a high-efficiency and standards-compliant 20W Interchangeable PD Charger. Designed for use in applications such as industrial control and automation systems. This series is supplied with a Interchangeable input connection and supports input voltages of 90~264V AC 47~63Hz. Certified to UKCA, CE, FCC, TUV-GS, cETLus, RCM (C-Tick), SAA, CCC, PSE, KC, RoHS, REACH and compliant with EN 62368-1/UL 62368-1/GB 4943-1/J 62368-1/K 60950-1. Ideal for AV and ITE manufacturers, this product range offers efficient, adaptable power units for demanding environments. If you can’t find what you need, contact us for alternative or tailored options.

Features

Input Range 90~264V AC
Approved to UKCA, CE, FCC, TUV-GS, cETLus, RCM (C-Tick), SAA, CCC, PSE, KC, RoHS, REACH
UL/EN 62368-1 Safety Approved
Meets Efficiency Level VI & (EU) 2019/1782
EMC Class B Certified
Single Output 5V DC

Basic Specification

Product Type	External Power Supply (PSU) Adapter Interchangeable Power Supply
Input Voltage	90~264V AC 47~63Hz
Output Power	20W
Number of Outputs	Single
Input Connection	Interchangeable
Dimensions	53.4x39x26.8mm
Industry	ITE, Audio & Video
Standards	EN 62368-1, UL 62368-1, GB 4943-1, J 62368-1, K 60950-1
