Interchangeable PD Charger02PD0202C

The PD0202C is a Single output 5V DC 3A 15W model and provides the performance expected in trusted applications. The 02PD-xy-C Series is a high-efficiency and standards-compliant 20W Interchangeable PD Charger. Designed for use in applications such as industrial control and automation systems. This series is supplied with a Interchangeable input connection and supports input voltages of 90~264V AC 47~63Hz. Certified to UKCA, CE, FCC, TUV-GS, cETLus, RCM (C-Tick), SAA, CCC, PSE, KC, RoHS, REACH and compliant with EN 62368-1/UL 62368-1/GB 4943-1/J 62368-1/K 60950-1. Ideal for AV and ITE manufacturers, this product range offers efficient, adaptable power units for demanding environments. If you can’t find what you need, contact us for alternative or tailored options.

Features

Input Range 90~264V AC
Approved to UKCA, CE, FCC, TUV-GS, cETLus, RCM (C-Tick), SAA, CCC, PSE, KC, RoHS, REACH
UL/EN 62368-1 Safety Approved
Meets Efficiency Level VI & (EU) 2019/1782
EMC Class B Certified
Single Output 5V DC

Basic Specification

Product Type	External Power Supply (PSU) Adapter Interchangeable Power Supply
Input Voltage	90~264V AC
Output	5V DC 3A
Output Power	15W
Number of Outputs	Single
Efficiency	81.4%
Output Connector	Interchangeable
Dimensions	53.4x39x26.8mm
Industry	ITE, Audio & Video
Standards	EN 62368-1, UL 62368-1, GB 4943-1, J 62368-1, K 60950-1
