Encapsulated DC DC Converter4114DC-05D15NP2-H3

The 14DC-05D15NP2X is a Dual output ±15V DC ±0.067A 2W model and supplies an isolated secondary rail from a fixed DC bus, running from a 5V DC input (4.5-5.5V) in a SIP7 package with 1.5KV DC or 3KV DC (H3) isolation. The 4114DC-2W Series is a 2W encapsulated DC/DC converter range with unregulated single outputs from 3.3V to 24V and dual outputs from ±3.3V to ±24V. Efficiency reaches 89%, no-load input current is as low as 5mA and short-circuit protection is continuous, giving designers a compact isolated rail in an industry standard pinout. This series is supplied with a Pin Connection input connection in a 7 pin SIP package, with fixed 5V, 12V, 15V and 24V DC input versions. Certified to CE, cULus, CB, RoHS and compliant with UL/CSA 62368-1/IEC 62368-1/EN 62368-1/EN 55032/EN 55035 Standards. These are primarily used in ITE, Audio & Video Industries, and customised solutions are available upon request.
