43QAE150-48S05

DC/DC ConvertersQuarter Brick

Ideal Power QAE150-48S05 5V DC 25A Single output 125W model. Certified to UKCA, CE, CB, cURus, RoHS, REACH & EN 62368-1/IEC 62368-1/UL 62368-1 Standards and complies with the relevant Efficiency Regulations. These are primarily used in ITE, Audio & Video Industries and customised solutions are available upon request.

Features

2:1 Wide Input Range
Approved to UKCA, CE, cURus
Available with optional heatsink (HS)
Efficiency up to 92%
EMC Class A & B
Operating Temperature Range: -40°C~105°C
Safety Standards to IEC/UL/EN 62368-1
Single 150W Output Models

Basic Specification

Product Type	DC/DC Converters DC/DC PCB Mount Power Supply
Input Voltage	16.5~75V DC
Output	5V DC 25A
Output Power	125W
Number of Outputs	Single
Efficiency	91.0%
Output Connector	Pin Connection
Dimensions	1.45x2.28x0.5"
Industry	ITE, Audio & Video
Standards	EN 62368-1, IEC 62368-1, UL 62368-1

Pdf Spec Sheet

3D Drawings

Other Models in this series

Compare Products 0/4

Compare	Model	Output Voltage	Current	Power	Additional Info
Compare	43QAE150-12S3P3	3.3V DC	30A	99W	Download Pdf
Compare	43QAE150-24S3P3	3.3V DC	30A	99W	Download Pdf
Compare	43QAE150-48S3P3	3.3V DC	30A	99W	Download Pdf
Compare	43QAE150-24S48	48V DC	2.5A	120W	Download Pdf
Compare	43QAE150-12S48	48V DC	2.5A	120W	Download Pdf
Compare	43QAE150-24S05	5V DC	24A	120W	Download Pdf
Compare	43QAE150-24S12	12V DC	10A	120W	Download Pdf
Compare	43QAE150-24S15	15V DC	8A	120W	Download Pdf
Compare	43QAE150-24S24	24V DC	5A	120W	Download Pdf
Compare	43QAE150-24S30	30V DC	4A	120W	Download Pdf
Compare	43QAE150-12S05	5V DC	24A	120W	Download Pdf
Compare	43QAE150-12S12	12V DC	10A	120W	Download Pdf
Compare	43QAE150-12S15	15V DC	8A	120W	Download Pdf
Compare	43QAE150-12S24	24V DC	5A	120W	Download Pdf
Compare	43QAE150-12S30	30V DC	4A	120W	Download Pdf
Compare	43QAE150-48S12	12V DC	12A	144W	Download Pdf
Compare	43QAE150-48S48	48V DC	3A	144W	Download Pdf
Compare	43QAE150-48S24	24V DC	6A	144W	Download Pdf
Compare	43QAE150-48S30	30V DC	5A	150W	Download Pdf
Compare	43QAE150-48S15	15V DC	10A	150W	Download Pdf
