43QAE100-24S24

DC/DC ConvertersQuarter Brick

Ideal Power QAE100-24S24 24V DC 3.7A Single output 88.8W model. Certified to UKCA, CE, CB, cURus, RoHS, REACH & EN 62368-1/IEC 62368-1/UL 62368-1 Standards and complies with the relevant Efficiency Regulations. These are primarily used in ITE, Audio & Video Industries and customised solutions are available upon request.

Features

2:1 Wide Input Range
Approved to UKCA, CE, cURus
Available with optional heatsink (HS)
Efficiency Up to 93%
EMC Class A & B
Operating Temperature Range: -40°C~105°C
Safety Standards to IEC/UL/EN 62368-1
Single 100W Output Models

Basic Specification

Product Type	DC/DC Converters DC/DC PCB Mount Power Supply
Input Voltage	8.5~36V DC
Output	24V DC 3.7A
Output Power	88.8W
Number of Outputs	Single
Efficiency	92.0%
Output Connector	Pin Connection
Dimensions	1.45x2.28x0.5"
Industry	ITE, Audio & Video
Standards	EN 62368-1, IEC 62368-1, UL 62368-1

Pdf Spec Sheet

3D Drawings

Other Models in this series

Compare Products 0/4

Compare	Model	Output Voltage	Current	Power	Additional Info
Compare	43QAE100-12S3P3	3.3V DC	25A	82.5W	Download Pdf
Compare	43QAE100-24S3P3	3.3V DC	25A	82.5W	Download Pdf
Compare	43QAE100-48S3P3	3.3V DC	25A	82.5W	Download Pdf
Compare	43QAE100-24S48	48V DC	1.8A	86.4W	Download Pdf
Compare	43QAE100-12S48	48V DC	1.8A	86.4W	Download Pdf
Compare	43QAE100-12S24	24V DC	3.7A	88.8W	Download Pdf
Compare	43QAE100-12S30	30V DC	3A	90W	Download Pdf
Compare	43QAE100-12S05	5V DC	18A	90W	Download Pdf
Compare	43QAE100-12S12	12V DC	7.5A	90W	Download Pdf
Compare	43QAE100-12S15	15V DC	6A	90W	Download Pdf
Compare	43QAE100-24S05	5V DC	18A	90W	Download Pdf
Compare	43QAE100-24S12	12V DC	7.5A	90W	Download Pdf
Compare	43QAE100-24S15	15V DC	6A	90W	Download Pdf
Compare	43QAE100-24S30	30V DC	3A	90W	Download Pdf
Compare	43QAE100-48S05	5V DC	21A	105W	Download Pdf
Compare	43QAE100-48S15	15V DC	7A	105W	Download Pdf
Compare	43QAE100-48S30	30V DC	3.5A	105W	Download Pdf
Compare	43QAE100-48S48	48V DC	2.2A	105.6W	Download Pdf
Compare	43QAE100-48S24	24V DC	4.5A	108W	Download Pdf
Compare	43QAE100-48S12	12V DC	9A	108W	Download Pdf
