28SFB036280-V-x-B600-IP
Full Brick DC/DC Converters
Ideal Power SFB036280-V-x-B600 28V DC 21.42A Single output 599.76W model. Certified to UKCA, CE, RoHS, REACH & EN 62368-1/IEC 62368-1/EN 50155 Standards and complies with Efficiency Regulations. These are primarily used in ITE, Audio & Video, Railway Industries and customised solutions are available upon request.
Features
- 2:1/4:1 Wide Input Range
- Approved to CE, RoHS & REACH
- Efficiency up to 91%
- EMC Class A & B
- Operating Temperature Range: -45°C~105°C
- Safety Standards to IEC/EN 62368-1/EN 50155
- Single output 9~425V DC
Basic Specification
| Product Type | DC/DC Converters DC/DC PCB Mount Power Supply |
|---|---|
| Input Voltage | 18~75V DC |
| Output | 28V DC 21.42A |
| Output Power | 599.8W |
| Number of Outputs | Single |
| Efficiency | 88.0% |
| Output Connector | Pin Connection |
| Dimensions | 61.4x61x15.0mm |
| Industry | ITE, Audio & Video, Railway |
| Standards | EN 62368-1, IEC 62368-1, EN 50155 |
