23SW-00240075-S10

AC/DC Lugged External Desktop Power Supply

Ideal Power 23SW-00240075-S10 24V DC 0.75A Single output 18W model. Certified to UKCA, CE, TUV, RCM (C-Tick), RoHS, REACH & EN 62368-1/IEC 62368-1/UL 62368-1 Standards and complies with (EU) 2019/1782, Level VI Efficiency Regulations. These are primarily used in ITE, Audio & Video Industries and customised solutions are available upon request.

Add compare
Home Product Clearance Lugged Desktop Power supply 23SW-xyz-S10 23SW-00240075-S10

Features

  • Approved to CE, TUV, cULus, RCM (C-Tick), RoHS & REACH
  • EMC EN 61000-3-2, EN 55032 Class B
  • Operating Temperature Range: 0~40°
  • OVP, OCP, OTP, SCP
  • Safety standards to IEC/EN/UL 62368-1
  • Single Output 9~24V DC
  • Universal Input 100~240V AC

Basic Specification

Product Type Product Clearance Lugged Desktop Power supply
Input Voltage 90~264V AC
Output 24V DC 0.75A
Output Power 18W
Number of Outputs Single
Efficiency
Output Connector 2.1 x 5.5 x 12 mm
Dimensions 73.8x49.4x27mm
Industry ITE, Audio & Video
Standards EN 62368-1, IEC 62368-1, UL 62368-1

Also Available From

CPC

Product Code: PW04317

Contact us

Reach out to discuss your power conversion requirements today.

Declaration

Click below to request the Series Declaration (PDF Download).

Request Declaration

Other Models in this series

Compare Products 0/4
Compare Model   Output Voltage Current Power Additional Info
Compare 23SW-00120100-S10
23SW-00120100-S10
 12V DC 1A 12W Download Pdf
Compare 23SW-00120150-S10
23SW-00120150-S10
 12V DC 1.5A 18W Download Pdf
Compare 23SW-00150120-S10
23SW-00150120-S10
 15V DC 1.2A 18W Download Pdf
Compare 23SW-00180100-S10
23SW-00180100-S10
 18V DC 1A 18W Download Pdf
Compare 23SW-00090200-S10
23SW-00090200-S10
 9V DC 2A 18W Download Pdf
