23SW-00180330-S10B-US

65W AC/DC Lugged External Desktop Power Supply (PSU)

Ideal Power's 23SW-xyz-S10B-US 65W AC/DC Lugged External Desktop Power Supply (PSU) Series are certified to CE, cULus, TUV, RCM (C-Tick), RoHS, REACH & EN 62368-1/IEC 62368-1/UL 62368-1 Standards and comply with (EU) 2019/1782, Level VI Efficiency Regulations. These are primarily used in ITE, Audio & Video Industries and customised solutions are available upon request.

Add compare

Features

  • Universal Input 100~240V AC
  • US Plug Type
  • Operating Temperature Range: 0~40°
  • Approved to CE, TUV, cULus, RCM (C-Tick), RoHS & REACH
  • Safety Standards to IEC/EN/UL 62368-1
  • EMC EN 61000-3-2, EN 55032 Class B
  • Single Output 9~24V DC
  • OVP, OCP, OTP, SCP

Basic Specification

Product Type External Power Supply (PSU) Lugged Desktop Power supply
Input Voltage 90~264V AC
Output 18V DC 3.3A
Output Power 59.4W
Number of Outputs Single
Efficiency
Output Connector 2.1 x 5.5 x 12 mm
Dimensions 71.05x106.4x34.2mm
Industry ITE, Audio & Video
Standards EN 62368-1, IEC 62368-1, UL 62368-1

Also Available From

Digikey

Product Code: 2882-23SW-00180330-S10B-US-ND

Contact us

Reach out to discuss your power conversion requirements today.

Declaration

Click below to request the Series Declaration (PDF Download).

Request Declaration

Other Models in this series

Compare Products 0/4
Compare Model   Output Voltage Current Power Additional Info
Compare 23SW-00090600-S10B-US 9V DC 6A 54W Download Pdf
Compare 23SW-00120500-S10B-US 12V DC 5A 60W Download Pdf
Compare 23SW-00150400-S10B-US 15V DC 4A 60W Download Pdf
Compare 23SW-00240271-S10B-US 24V DC 2.71A 65W Download Pdf
