23SW-00150120-S10

18W AC/DC Lugged External Desktop Power Supply (PSU)

Ideal Power's 23SW-xyz-S10 18W AC/DC Lugged External Desktop Power Supply (PSU) Series are certified to UKCA, CE, TUV, RCM (C-Tick), RoHS, REACH & EN 62368-1/IEC 62368-1/UL 62368-1 Standards and comply with (EU) 2019/1782, Level VI Efficiency Regulations. These are primarily used in ITE, Audio & Video Industries and customised solutions are available upon request.

Add compare

Features

  • Universal Input 100~240V AC
  • Operating Temperature Range: 0~40°
  • Approved to CE, TUV, cULus, RCM (C-Tick), RoHS & REACH
  • Safety Standards to IEC/EN/UL 62368-1
  • EMC EN 61000-3-2, EN 55032 Class B
  • Single Output 9~24V DC
  • OVP, OCP, OTP, SCP

Basic Specification

Product Type Product Clearance Lugged Desktop Power supply
Input Voltage 90~264V AC
Output 15V DC 1.2A
Output Power 18W
Number of Outputs Single
Efficiency
Output Connector 2.1 x 5.5 x 12 mm
Dimensions 73.8x49.4x27mm
Industry ITE, Audio & Video
Standards EN 62368-1, IEC 62368-1, UL 62368-1

Also Available From

CPC

Product Code: PW04315

Contact us

Reach out to discuss your power conversion requirements today.

Declaration

Click below to request the Series Declaration (PDF Download).

Request Declaration

Other Models in this series

Compare Products 0/4
Compare Model   Output Voltage Current Power Additional Info
Compare 23SW-00120100-S10 12V DC 1A 12W Download Pdf
Compare 23SW-00120150-S10 12V DC 1.5A 18W Download Pdf
Compare 23SW-00180100-S10 18V DC 1A 18W Download Pdf
Compare 23SW-00240075-S10 24V DC 0.75A 18W Download Pdf
Compare 23SW-00090200-S10 9V DC 2A 18W Download Pdf
