23SW-00120100-S10

AC/DC Lugged External Desktop Power Supply

Ideal Power's 23SW-xyz-S10 18W AC/DC Lugged External Desktop Power Supply (PSU) Series are certified to UKCA, CE, TUV, RCM (C-Tick), RoHS, REACH & EN 62368-1/IEC 62368-1/UL 62368-1 Standards and comply with (EU) 2019/1782, Level VI Efficiency Regulations. These are primarily used in ITE, Audio & Video Industries and customised solutions are available upon request.

Add compare
Home Product Clearance Lugged Desktop Power supply 23SW-xyz-S10 23SW-00120100-S10

Features

  • Universal Input 100~240V AC
  • Operating Temperature Range: 0~40°
  • Approved to CE, TUV, cULus, RCM (C-Tick), RoHS & REACH
  • Safety Standards to IEC/EN/UL 62368-1
  • EMC EN 61000-3-2, EN 55032 Class B
  • Single Output 9~24V DC
  • OVP, OCP, OTP, SCP

Basic Specification

Product Type Product Clearance Lugged Desktop Power supply
Input Voltage 90~264V AC
Output 12V DC 1A
Output Power 12W
Number of Outputs Single
Efficiency
Output Connector 2.1 x 5.5 x 12 mm
Dimensions 73.8x49.4x27mm
Industry ITE, Audio & Video
Standards EN 62368-1, IEC 62368-1, UL 62368-1

Contact us

Reach out to discuss your power conversion requirements today.

Declaration

Click below to request the Series Declaration (PDF Download).

Request Declaration

Other Models in this series

Compare Products 0/4
Compare Model   Output Voltage Current Power Additional Info
Compare 23SW-00090200-S10
23SW-00090200-S10
 9V DC 2A 18W Download Pdf
Compare 23SW-00120150-S10
23SW-00120150-S10
 12V DC 1.5A 18W Download Pdf
Compare 23SW-00150120-S10
23SW-00150120-S10
 15V DC 1.2A 18W Download Pdf
Compare 23SW-00180100-S10
23SW-00180100-S10
 18V DC 1A 18W Download Pdf
Compare 23SW-00240075-S10
23SW-00240075-S10
 24V DC 0.75A 18W Download Pdf
